Diagnostic training stand AUDIG1-1
GENERAL INFORMATION
The diagnostic training stand is designed to provide students with practical skills in performing vehicle diagnostics. The stand integrates professional fault-testing equipment that allows for the simulation and analysis of various electronic malfunctions in commercial vehicles. This stand serves as an essential training platform for future automotive diagnostics specialists.
Learning objectives
Learn to operate diagnostic equipment from various manufacturers.
Perform fault analysis and code reading for commercial vehicle systems.
Practice using different types of diagnostic testers under real-life conditions.
Become familiar with software used alongside diagnostic tools.
Develop the ability to apply appropriate diagnostic methodologies depending on the type of vehicle.
Equipment set includes
Truck V3 diagnostic module – A modular diagnostic device designed for commercial vehicle workshops. It connects to a computer via USB or Bluetooth and operates with ESI[tronic] 2.0 software.
A universal diagnostic device that connects to the vehicle and computer via Bluetooth, supporting commercial vehicle systems.
Diagnostic equipment with multiplexer technology, enabling compatibility with various vehicle communication protocols and supporting real-time diagnostics.
An advanced diagnostic device with Ethernet support, dual-channel oscilloscope, and integrated multimeter signal analysis.
Usage requirements
Power supply: 220–230 V AC, 50 Hz.
Workspace: at least 10 m² with the ability to connect a computer.
Computer interface: USB or Bluetooth connection for diagnostic software.
Simulation capability: CAN-BUS, OBD-II, EBS/ABS signals.
